CWFZ型海洋自我粉碎水平泵广泛应用于轻型工业，纸张 - 制作，纺织品，食品，化学品，动力行业，挖掘，船，城市污水排水以及水生文化，目前是中国使用固体颗粒，纤维，纤维，纸浆和混合悬架的媒体运输媒体中最理想的泵。
50Hz3φ380V的电源频率的性能和参数表：
| 类型 | （50Hz3φ380V）主要技术参数 | 电机类型电源kW | 重量 公斤 |
|||||
| 容量 M3/h |
头 m |
速度r/min | npshr m |
轴功率 KW |
||||
| 0.5CWFZ-20 | 5 | 20 | 2900 | 4 | Y90L-2H | 2.2 | ||
| 0.5CWFZ-25 | 5 | 25 | 2900 | 4 | Y90L-2H | 2.2 | ||
| 0.5CWFZ-30 | 5 | 30 | 2900 | 4 | Y112M-2H | 4 | ||
| 1CWFZ-20 | 10 | 20 | 2900 | 4.5 | Y90L-2H | 2.2 | ||
| 1CWFZ-25 | 10 | 25 | 2900 | 4.5 | Y112M-2H | 4 | ||
| 1CWFZ-30 | 10 | 30 | 2900 | 4.5 | Y112M-2H | 4 | ||
| 1CWFZ-35 | 10 | 35 | 2900 | 4.5 | Y132S1-2H | 5.5 | ||
| 1CWFZ-40 | 10 | 40 | 2900 | 4.5 | Y132S1-2H | 5.5 | ||
| 1CWFZ-50 | 10 | 50 | 2900 | 4.5 | Y132S2-2H | 7.5 | ||
| 1.5CWFZ-30 | 15 | 30 | 2900 | 5 | Y132S1-2H | 5.5 | ||
| 1.5CWFZ-35 | 15 | 35 | 2900 | 5 | Y132S1-2H | 5.5 | ||
| 2CWFZ-35 | 20 | 35 | 2900 | 5 | Y132S2-2H | 7.5 | ||
| 2CWFZ-40 | 20 | 40 | 2900 | 5 | Y132S2-2H | 7.5 | ||
| 5CWFZ-30 | 50 | 30 | 2950 | 4.5 | Y160M1-2H | 11 | ||
| 5CWFZ-40 | 50 | 40 | 2950 | 4.5 | Y180M-2H | 22 | ||
电源频率60Hz3φ440V的性能和参数表：
| 类型 | （60Hz3φ440V） | KW | 公斤 | |||||
| M3/h | 头 m |
r/min | m | KW | ||||
| 0.5CWFZ1-20 | 6 | 28 | 3500 | 4.5 | Y112M-2H | 4 | ||
| 0.5CWFZ1-25 | 6 | 36 | 3500 | 4.5 | Y112M-2H | 4 | ||
| 0.5CWFZ1-30 | 6 | 43 | 3500 | 4.5 | Y112M-2H | 4 | ||
| 1CWFZ1-20 | 12 | 28.5 | 3500 | 5 | Y132S1-2H | 5.5 | ||
| 1CWFZ1-25 | 12 | 35.5 | 3500 | 5 | Y132S2-2H | 7.5 | ||
| 1CWFZ1-30 | 12 | 43 | 3500 | 5 | Y132S2-2H | 7.5 | ||
| 1CWFZ1-35 | 12 | 51 | 3550 | 5 | Y160M1-2H | 11 | ||
| 1CWFZ1-40 | 12 | 59 | 3550 | 5 | Y160M1-2H | 11 | ||
| 1CWFZ1-50 | 12 | 73 | 3550 | 5 | Y160M2-2H | 15 | ||
| 1.5CWFZ1-30 | 18 | 44 | 3550 | 5.5 | Y160M1-2H | 11 | ||
| 1.5CWFZ1-35 | 18 | 51 | 3550 | 5.5 | Y160M1-2H | 11 | ||
| 2CWFZ1-35 | 24.5 | 51 | 3550 | 5.5 | Y160M1-2H | 11 | ||
| 2CWFZ1-40 | 24.5 | 58 | 3550 | 5.5 | Y160M2-2H | 15 | ||
| 5CWFZ1-30 | 60 | 42 | 3550 | 5 | Y160L-2H | 18.5 | ||
| 5CWFZ1-40 | 60 | 57 | 3580 | 6 | Y200L2-2H | 37 | ||
